Efficient knockout of TOM1 gene using CRISPR/Cas9 in Indian tomato cultivar ‘Arka Vikas’
*Article not assigned to an issue yet
Sandhya Dulam, Jogam Phanikanth, Sheri Vijay, Peddaboina Venkataiah, Allini Venkateswar Rao, Abbagani Sadanandam
Research Articles | Published: 08 January, 2025
First Page: 0
Last Page: 0
Views: 1705
Keywords: Arka Vikas, CRISPR/Cas, Genome editing, n Solanum lycopersicumn , TOM1
Abstract
Tomato is one of the commercial crop grown in all parts of the world. Tobacco Mosaic Virus (TMV) and Tomato mosaic virus (ToMV) cause heavy yield loss in tomato. The tonoplast membrane-associated proteins TOM1 and TOM3 are required for the efficient multiplication of Tobamoviruses. Simultaneous mutations in any one of these genes inhibit the multiplication of Tobamoviruses. We have prepared guide RNA (gRNA) in the exon region of SlTOM1.3 and cloned it into the pHSE401 vector. Polymerase chain reaction (PCR) and sequencing confirmed the plasmid DNA. The confirmed plasmid product (pHSE401-SlTOM1.3) was transferred to Agrobacterium tumefaciens strain LBA4404 for plant transformation. PCR analysis was conducted with non-transformed (WT-wild type) genomic DNA and transformed plants for hptII and Cas9 gene amplification. A total of 16 transformed and wild-type plants performed nucleotide sequencing for mutation analysis in SlTOM1.3 gene. Among 16 plants, mutations were observed in 9 plants. We have observed several insertions and deletions (indels) in target sequence of corresponding gene. A single base pair alteration (either insertion or deletion) in the targeted gene can change the frameshift of a particular gene and result in abnormal protein. So, this CRISPR-Cas9 mediated genome editing protocol developed in tomato will be feasible for developing resistance to several viral pathogens of Tobamovirus genus.
References
Ali EM, Kobayashi K, Yamaoka N, Ishikawa M, Nishiguchi M (2013) Graft transmission of RNA silencing to non-transgenic scions for conferring virus resistance in tobacco. PLoS ONE 8(5):e63257
Ali ME, Ishii Y, Taniguchi JI, Waliullah S, Kobayashi K, Yaeno T, Yamaoka N, Nishiguchi M (2018) Conferring virus resistance in tomato by independent RNA silencing of three tomato homologs of Arabidopsis TOM1. Arch Virol 163:1357–1362
Asano M, Satoh R, Mochizuki A, Tsuda S, Yamanaka T, Nishiguchi M, Hirai K, Meshi T, Naito S, Ishikawa M (2005) Tobamovirus-resistant tobacco generated by RNA interference directed against host genes. FEBS Lett 579(20):4479–4484
Bae EK, Choi H, Choi JW, Lee H, Kim SG, Ko JH, Choi YI (2021) Efficient knockout of the phytoene desaturase gene in a hybrid poplar (Populus alba × Populus glandulosa) using the CRISPR/Cas9 system with a single gRNA. Trans Res 30(6):837–849
Bari VK, Nassar JA, Aly R (2021) CRISPR/Cas9 mediated mutagenesis of MORE AXILLARY GROWTH 1 in tomato confers resistance to root parasitic weed Phelipanche aegyptiaca. Sci Rep 11(1):1–11
Binyameen B, Khan Z, Khan SH, Ahmad A, Munawar N, Mubarik MS, Riaz H, Ali Z, Khan AA, Qusmani AT, Abd-Elsalam KA (2021) Using multiplexed CRISPR/Cas9 for suppression of cotton leaf curl virus. Int J Mol Sci 22(22):12543
Bouzroud S, Gasparini K, Hu G, Barbosa MAM, Rosa BL, Fahr M, Bendaou N, Bouzayen M, Zsögön A, Smouni A, Zouine M (2020) Down regulation and loss of auxin response factor 4 function using CRISPR/Cas9 alters plant growth, stomatal function and improves tomato tolerance to salinity and osmotic stress. Genes 11(3):272
Chaudhuri A, Halder K, Datta A (2022) Classification of CRISPR/Cas system and its application in tomato breeding. Theor Appl Genet 135(2):367–387
Davey MR, Soneji JR, Rao MN, Kourmpetli S, Bhattacharya A, Kole C (2010) Generation and deployment of transgenic crop plants: an overview. In: Kole C, Michler CH, Abbott AG, Hall TC (eds) Transgenic crop plants: principles and development. Springer, Berlin Heidelberg, pp 1–29
Deng L, Wang H, Sun C, Li Q, Jiang H, Du M, Li CB, Li C (2018) Efficient generation of pink-fruited tomatoes using CRISPR/Cas9 system. J Gen Genom 45(1):51–54
Doyle JJ, Doyle JL (1990) Isolation of plant DNA from fresh tissue. Focus 12(13):39–40
Engler C, Kandzia R, Marillonnet S (2008) A one pot, one step, precision cloning method with high throughput capability. PLoS ONE 3(11):e3647
Fujisaki K, Ravelo GB, Naito S, Ishikawa M (2006) Involvement of THH1, an Arabidopsis thaliana homologue of the TOM1 gene, in tobamovirus multiplication. J Gen Virol 87(8):2397–2401
Hagiwara Y, Komoda K, Yamanaka T, Tamai A, Meshi T, Funada R, Tsuchiya T, Naito S, Ishikawa M (2003) Subcellular localization of host and viral proteins associated with tobamovirus RNA replication. EMBO J 22(2):344–353
Hong Y, Meng J, He X, Zhang Y, Liu Y, Zhang C, Luan Y (2021) Editing miR482b and miR482c simultaneously by CRISPR/Cas9 enhanced tomato resistance to Phytophthora infestans. Phytopathology 111(6):1008–1016
Hooghvorst I, Lopez-Cristoffanini C, Nogues S (2019) Efficient knockout of phytoene desaturase gene using CRISPR/Cas9 in melon. Sci Rep 9(1):1–7
Hu N, Xian Z, Li N, Liu Y, Huang W, Yan F, Su D, Chen J, Li Z (2019) Rapid and user-friendly open-source CRISPR/Cas9 system for single-or multi-site editing of tomato genome. Hort Res 6:7
Hu Q, Zhang H, Zhang L, Liu Y, Huang C, Yuan C, Chen Z, Li K, Larkin RM, Chen J, Kuang H (2021) Two TOBAMOVIRUS MULTIPLICATION 2A homologs in tobacco control asymptomatic response to tobacco mosaic virus. Plant Physiol 187(4):2674–2690
Ishibashi K, Kubota K, Kano A, Ishikawa M (2023) Tobamoviruses: old and new threats to tomato cultivation. J Gen Plant Pathol 89(6):305–321
Ishikawa M, Yoshida T, Matsuyama M, Kouzai Y, Kano A, Ishibashi K (2022) Tomato brown rugose fruit virus resistance generated by quadruple knockout of homologs of TOBAMOVIRUS MULTIPLICATION1 in tomato. Plant Physiol 189:679–686
Jang G, Joung YH (2019) CRISPR/Cas-mediated genome editing for crop improvement: current applications and future prospects. Plant Biotechnol Rep 13:1–10
Jinek MK, Chylinski I, Fonfara M, Hauer JA, Doudna CE (2012) A programmable dual-RNA-guided DNA endonuclease in adaptive bacterial immunity. Science 337(6096):816–821
Jogam P, Sandhya D, Alok A, Peddaboina V, Allini VR, Zhang B (2022) A review on CRISPR/Cas-based epigenetic regulation in plants. Int J Biol Macromol 219:1261–1271
Jogam P, Sandhya D, Alok A, Peddaboina V, Singh SP, Abbagani S, Zhang B, Allini VR (2023) Editing of TOM1 gene in tobacco using CRISPR/Cas9 confers resistance to Tobacco mosaic virus. Mol Biol Rep 50:5165–5176
Khoshkhatti N, Eini O, Koolivand D, Pogiatzis A, Klironomos JN, Pakpour S (2020) Differential response of mycorrhizal plants to tomato bushy stunt virus and tomato mosaic virus infection. Microorganisms 8(12):2038
Kravchik M, Shnaider Y, Abebie B, Shtarkman M, Kumari R, Kumar S, Leibman D, Spiegelman Z, Gal-On A (2022) Knockout of SlTOM1 and SlTOM3 results in differential resistance to tobamovirus in tomato. Mol Plant Pathol 23:1278–1289
Kumar S, Dubey AK, Karmakar R, Kini KR, Mathew MK, Prakash HS (2012) Inhibition of TMV multiplication by siRNA constructs against TOM1 and TOM3 genes of Capsicum annuum. J Virol Methods 86(1–2):78–85
Liu H, Wang K, Jia Z, Gong Q, Lin Z, Du L, Pei X, Ye X (2020) Efficient induction of haploid plants in wheat by editing of TaMTL using an optimized Agrobacterium-mediated CRISPR system. J Exp Bot 71(4):1337–1349
Mlambo T, Nitsch S, Hildenbeutel M, Romito M, Müller M, Bossen C, Diederichs S, Cornu TI, Cathomen T, Mussolino C (2018) Designer epigenome modifiers enable robust and sustained gene silencing in clinically relevant human cells. Nucleic Acids Res 46(9):4456–4468
Murashige T, Skoog F (1962) A revised medium for rapid growth and bio assays with tobacco tissue cultures. Physiol Plant 15(3):473–497
Negi C, Vasistha NK, Singh D, Vyas P, Dhaliwal HS (2022) Application of CRISPR-mediated gene editing for crop improvement. Mol Biotechnol 64:1198–1217
Ortigosa A, Gimenez-Ibanez S, Leonhardt N, Solano R (2019) Design of a bacterial speck resistant tomato by CRISPR/Cas9-mediated editing of SlJAZ2. Plant Biotechnol J 17(3):665–673
Ren C, Liu X, Zhang Z, Wang Y, Duan W, Li S, Liang Z (2016) CRISPR/Cas9-mediated efficient targeted mutagenesis in Chardonnay (Vitis vinifera L.). Sci Rep 6:32289
Roossinck MJ, Sabanadzovic S, Okada R, Valverde RA (2011) The remarkable evolutionary history of endornaviruses. J Gen Virol 92:2674–2678
Sandhya D, Jogam P, Allini VR, Abbagani S, Alok A (2020) The present and potential future methods for delivering CRISPR/Cas9 components in plants. J Genet Eng Biotechnol 8(1):1–11
Sandhya D, Jogam P, Venkatapuram AK, Savitikadi P, Peddaboina V, Allini VR, Abbagani S (2022) Highly efficient Agrobacterium-mediated transformation and plant regeneration system for genome engineering in tomato. Saudi J Biol Sci 29(6):103292
Sufyan M, Daraz U, Hyder S, Zulfiqar U, Iqbal R, Eldin SM, Rafiq F, Mahmood N, Shahzad K, Uzair M, Fiaz S, Ali I (2023) An overview of genome engineering in plants, including its scope, technologies, progress and grand challenges. Funct Int Genom 23:119
Tian S, Jiang L, Gao Q, Zhang J, Zong M, Zhang H, Ren Y, Guo S, Gong G, Liu F, Xu Y (2017) Efficient CRISPR/Cas9-based gene knockout in watermelon. Plant Cell Rep 36(3):399–406
Tiwari JK, Singh AK, Behera TK (2023) CRISPR/Cas genome editing in tomato improvement: advances and applications. Front Plant Sci 14:1121209
van den Elzen PJM, Townsend J, Lee KY, Redbrook JR (1985) A chimaeric hygromycin resistance gene as a selectable marker in plant cells. Plant Mol Biol 5:299–302
Wang X, Shen Z, Li C, Bai Y, Li Y, Zhang W, Li Z, Jiang C, Cheng L, Yang A, Liu D (2024) Fine mapping and identification of two NtTOM2A homeologs responsible for tobacco mosaic virus replication in tobacco (Nicotiana tabacum L.). BMC Plant Biol 24(1):67. https://doi.org/10.1186/s12870-024-04744-y
Xing HL, Dong L, Wang ZP, Zhang HY, Han CY, Liu B, Wang XC, Chen QJ (2014) A CRISPR/Cas9 toolkit for multiplex genome editing in plants. BMC Plant Biol 14(1):1–12
Yamanaka T, Ohta T, Takahashi M, Meshi T, Schmidt R, Dean C, Naito S, Ishikawa M (2000) TOM1, an Arabidopsis gene required for efficient multiplication of a tobamovirus, encodes a putative transmembrane protein. Proc Natl Acad Sci USA 97:10107–10112
Author Information
Department of Biotechnology, Kakatiya University, Warangal, India
