Analytical quality by design (AQbD)-based approach to develop an extraction method for high recovery of Lupeol from Vernonia cinerea followed by discriminating analysis for geographical variation
*Article not assigned to an issue yet
Dahiya Jyoti, Bolleddu Rajesh, Mangal Anupam K., Abdullah Salik, Bhardwaj Yashpal, Arya Jagdish, Walson Vishnu, Babu Gajji
Research Articles | Published: 18 June, 2026
First Page: 0
Last Page: 0
Views: 102
Keywords: n Vernonia cinerean , Quality by design (QbD), One factor at a time (OFAT), Central composite rotatable design (CCRD), Design of experiment (DoE), Response surface methodology (RSM), TLC-densitometry
Abstract
Preparation of extract is an essential initial step in recovering bio-active components from medicinal plants. The separation of bio-molecules depends on numerous factors, and minor alterations in the values of these factors could affect the extraction. Consequently, it becomes vital to check the effect of all parameters errorlessly. This study also includes a discriminating analysis to select the best raw material with high lupeol content, triterpenoid content and antioxidant activity. Quality by design is emerging as a systematic approach for developing a process with quality output. In the present work, analytical quality by design was used to develop, optimize, and validate a process of extraction for Vernonia cinerea whole plant following single-factor studies and response surface methodology. Here, a validated TLC-densitometry method was utilized to check the content of the quantitative analytical marker Lupeol. The studies showed that two variables, ethanol %, and solvent volume affects the extraction procedure independently. These were selected and their effect was further optimized by Central composite rota-table Design (CCRD). ANOVA was used to check the model’s fitness based on regression coefficients and other quality assessment parameters. The generated information recommends the usage of 50 mL/g of 80% ethanol for 30 min (× 2 cycles of reflux) with desirability of 0.927 for maximum extraction of Lupeol by reflux method. The developed extraction protocol could be helpful for all the future extraction processes involved in plant standardization and manufacturing of herbal formulations of Vernonia cinerea (Sahadevi). Furthermore, samples collected from plain areas contain a higher amount of bioactive with biological activity than high altitude samples.
References
Acharya R, Sharma B, Singh R, Jain P (2019) Phytochemical and high-performance liquid chromatography analysis of extract of Vernonia cinerea. J Drug Delivery Ther 9(1):229–232
Asha R, Devi VG, Abraham A (2016) Lupeol, a pentacyclic triterpenoid isolated from Vernonia cinerea attenuate selenite induced cataract formation in Sprague Dawley rat pups. Chemico-Biol Interact 245:20–29
Aquino R, Morelli S, Lauro MR, Abdo S, Saija A, Tomaino A (2001) Phenolic constituents and antioxidant activity of an extract of Anthurium versicular leaves. J Natl Prod 64:1019–1023
Azwanida NN (2015) A review on the extraction methods use in medicinal plants, principle, strength and limitation. Med Aromatic Plants 4(3):1–6
Belwal T (2016) Optimization extraction conditions for improving phenolic content and antioxidant activity in Berberis asiatica fruits using response surface methodology (RSM). Food Chem 207:115–124
Brusotti G, Cesari I, Dentamaro A, Caccialanza G, Massolini G (2014) Isolation and characterization of bioactive compounds from plant resources: the role of analysis in the ethnopharmacological approach. J Pharm Biomed Anal 87:218–228
Dahiya J, Kumar D, Hazra K, Bolleddu R, Dutta S, Mall S, Babu G (2024) Evaluation and observance of variation in chemical and antioxidant activity changes during the development of fenugreek seeds following thin-layer chromatography–fingerprint and marker analysis. JPC–J Planar Chromatography–Modern TLC, 1–14
Dai J, Russell JM (2010) Plant phenolics: extraction, analysis and their antioxidant and anticancer properties. Molecules 15(10):7313–7352
Dorta E, Loba MG, González. M (2013) Optimization of factors affecting extraction of antioxidants from mango seed. Food Bioprocess Technol 6:1067–1081
Dogra NK, Kumar S (2015) A review on ethno-medicinal uses and pharmacology of Vernonia cinerea Less. Nat Prod Res 29(12):1102–1117
Goggi A, Malpathak N (2017) Antioxidant activities of root, stem and leaves of Vernonia cinerea (L) Less. Free Radicals Antioxid 7(2):178–183
Guevara-Terán M, Gonzalez-Paramás AM, Beltrán-Noboa A, Giampieri F, Battino M, Tejera E, Alvarez-Suarez JM (2023) Influence of altitude on the physicochemical composition and antioxidant capacity of strawberry: a preliminary systematic review and meta-analysis. Phytochem Rev 22(6):1567–1584
Hai-Yan C, Murthy HN, Moh SH, Cui YY, Lee EJ, Paek KY (2014) Comparison of conventional and ultrasoundassisted methods for extraction of nutraceutical compounds from Dendrobium candidum. CyTA – J Food 12(4):355–359
Hayouni EA, Abedrabba M, Bouix M, Hamdi M (2007) The effects of solvents and extraction method on the phenolic contents and biological activities in vitro of Tunisian Quercus coccifera L. and Juniperus phoenicea L. fruit extracts. Food Chem 105(3):1126–1134
Hiba NR, Nada ED, Hobaika Z, Boussetta N, Vorobiev E, Richard GM, Louka N (2014) Extraction of total phenolic compounds, flavonoids, anthocyanins and tannins from grape byproducts by response surface methodology. influence of solid-liquid ratio, particle size, time, temperature and solvent mixtures on the optimization process. Food Nutr Sci 5:397–409
ICH (1994) Harmonised Tripartite guideline. Validation of analytical procedures: text and methodology Q2(R1)
Iwalewa EO, Iwalewa OJ, Adeboye JO (2003) Analgesic, antipyretic, anti-inflammatory effects of methanol, chloroform and ether extracts of Vernonia cinerea less leaf. J Ethnopharmacol 86(2–3):229–234
Keser S, Celik S, Turkoglu S, Yilmaz O, Turkoglu I (2012) Hydrogen peroxide radical scavenging and total antioxidant activity of hawthorn. Chem J 2(1):9–1236
Khadiga AA, Taleb, Galal GF (2018) A comparative study between one-factor-at-a-time and minimum runs resolution-IV methods for enhancing the production of polysaccharide by Stenotrophomonas daejeonensis and Pseudomonas geniculate. Annals Agricultural Sci 63:173–180
Kumar N, Kaur B, Shukla S, Patel MK, Thakur MS, Kumar R, Saxena S (2022) Comparative analysis of phytochemical composition and anti-oxidant and anti-inflammatory benefits of Eruca sativa grown at high altitude than at lower altitude. Chem Pap 76(12):7759–7782
Lei W, Zang W, Yin L, Yan F, Xu Y, Chen F (2015) Extraction optimization of total triterpenoids from Jatropha curcas leaves using response surface methodology and evaluations of their antimicrobial and antioxidant capacities. Electron J Biotechnol 18:88–95
Pathirana CL, Shahidi F (2005) Optimization of extraction of phenolic compounds from wheat using response surface methodology. Food Chem 93:47–56
Prasad KN, Hassan FA, Yang B, Kong KW, Ramanan RN, Azlan A, Ismail A (2011) Response surface optimisation for the extraction of phenolic compounds and antioxidant capacities of underutilised Mangifera pajang Kosterm. peels. Food Chem 128:1121–1127
Sehwag S, Das M (2013) Antioxidant activity: an overview. J Food Sci Technol 2:1–10
Silva EM, Rogez H, Larondelle Y (2007) Optimization of extraction of phenolics from Inga edulis leaves using response surface methodology. Sep Purif Technol 55:381–387
Slavov G, Robson P, Jensen E, Hodgson E, Farrar K, Allison G Thomas-jones SIAN. (2012) Contrasting geographic patterns of genetic variation for molecular markers vs. phenotypic traits in the energy
Tan MC, Tan CP, Ho CW (2013) Effects of extraction solvent system, time and temperature on total phenolic content of henna (Lawsonia inermis) stems. Int Food Res J 20(6):3117–3123
Tambe E, Gotmare S (2021) A review of extraction methods, geographic variation in chemical composition and identification of marker compounds in bud, leaf and stem clove oil. Res J Chem Environ 25(12):149–169
Turkmen N, Sari F, Velioglu YS (2006) Effects of extraction solvents on concentration and antioxidant activity of black and black mate tea polyphenols determined by ferrous tartrate and Folin–Ciocalteu methods. Food Chem 99:835–841
Trang NM, Vinh LB, Phong NV, Yang SY (2024) Traditional uses, phytochemistry, and pharmacological activities of Vernonia cinerea (L.) less.: an updated review. Nutrients 16(9):1396
Varsha V, Suresh SN, Prejeena V (2016) Phytochemical screening, GC-MS analysis and antibacterial activity of Vernonia cinerea leaves. Int J Recent Adv Multidiscipl Res 3(12):2079–2085
Wei-Liu Y, Yanying R, Yang C, Wan B, Xu, Cao S (2010) Optimization of total flavonoid compound extraction from Gynura medica leaf using response surface methodology and chemical composition analysis. Int J Mol Sci 11:4750–4763
Wannasetdecho T, Sonklin C, Pranee S, Seeyangnok S (2022) Chemical constituents of Vernonia cinerea (L.) less and their antioxidant activity. J Food Sci Agri Technol (JFAT) 6(1):25–29
Author Information
Department of Pharmacognosy, Central Ayurveda Research Institute, CCRAS, Ministry of AYUSH, Kolkata, India
